Mobile Industrial Laser Cleaning System for Rust, Paint and Surface Coating Removal

Presentation of the equipment's characteristics

The Greenstone mobile industrial laser cleaning system is designed for high-efficiency removal of rust, paint, oil, oxide layers, coatings, and surface contaminants from metal and selected non-metal materials. The system combines portability, high cleaning efficiency, and precise surface treatment performance, making it ideal for industrial maintenance, manufacturing, remanufacturing, and surface preparation applications.

This equipment is widely used in aluminum alloy oxide cleaning before welding, battery tray weld cleaning, railway bogie weld inspection preparation, automotive sheet metal refurbishment, and precision cleaning of grooves, holes, and complex workpieces that are difficult to access using traditional mechanical methods. With its flexible handheld operation, stable laser output, and environmentally friendly cleaning process, the system provides a reliable solution for modern industrial surface treatment applications.

This series of products is mainly used for cleaning pollutants such as local rust, paint, coating, oil, oxide film, etc. on various metal surfaces. It can also be used for cleaning the surfaces of non-metallic substrates such as ceramics, glass, and composite materials. Typical application scenarios include cleaning of natural oxide film before aluminum alloy welding, cleaning of black and gray oxide after battery tray welding, cleaning before flaw detection of train bogie welds, cleaning before renovation of automobile sheet metal parts, and cleaning of small holes and grooves of steel components that cannot be reached by wire brushes.

Product advantages

Ultra-light cleaning head, flexible operation
Can clean parts of different shapes
Infrared indicator focus
Sealed chassis, dustproof and high temperature resistant
Equipped with universal wheels, flexible movement
100-1000W power full coverage
Green, environmentally friendly, and pollution-free. Dust, odor, etc. generated by laser cleaning can be filtered out through the attached activated carbon dust removal equipment;
Laser cleaning has high efficiency and good cleaning effect;
The laser cleaning process does not damage the substrate and has little temperature effect on the substrate;
It has strong adaptability and can clean complex workpieces or work under complex working conditions.

Parameter Name	Parameter Value
Device Model	GSTRLC600 – 500/1000W
Laser Power	500W/1000W
Device Weight	Approx. 180kg
Cleaning Head Weight	4.5kg (Single Mode) / 2kg (Multi Mode)
Fiber Length	10m
Dimensions	913mm * 573mm * 881mm
Cooling Method	Water Cooling
Laser Wavelength	1064nm
Scanning Width	Adjustable 5-150mm
Scanning Patterns	10 optional scanning patterns (—, ○, ▲, ∞, etc.)
Power Consumption @25℃	<4000W / <6000W
Supply Air Pressure	0.4MPa clean compressed air (water and oil removed)

Note: The above parameters are based on the 500W/1000W water-cooled laser. Performance parameters may vary for different power levels and models. All technical parameters are subject to the technical solutions provided by us.
