Prezentarea caracteristicilor echipamentului

Greenstone-Tech provides a customizable large-area laser cleaning system designed for high-efficiency surface preparation on large workpieces—especially for steel industry applications such as removing rust, oxide layers, oil stains, and surface contaminants on wide plates and long materials.
With high automation and stable motion control, the system supports one-button automatic cleaning, adjustable scanning width, and efficient dust/fume management—helping improve cleaning consistency while reducing manual workload.

probe prelucrate
Echipament personalizat de curățare cu laser pe arie largă
Echipament personalizat de curățare cu laser pe arie largă
Echipament personalizat de curățare cu laser pe arie largă
Echipament personalizat de curățare cu laser pe arie largă

1) High Automation, One-Click Operation

Designed for high-throughput production, the system supports one-button fully automatic cleaning and can automatically adjust the laser cleaning path for efficient large-area processing.

2) Precision Focus Control with Auto Adjustment

Equipped with an automatic focus adjustment function to help compensate for workpiece deformation during processing, reducing focus fluctuation and improving cleaning consistency across the surface.

3) Synchronous Fume & Dust Purification

An integrated purification approach helps reduce the spread of dust, oil mist, and rust particles, supporting cleaner production and more stable operation during continuous cleaning tasks.

4) Stable System Architecture for Reliable Results

A dual-control design improves overall stability: one system focuses on cleaning head motion control, while another supports peripheral coordination (such as safety and purification), helping reduce vibration impact and maintain consistent cleaning performance.

5) Wide Customization Range for Different Production Lines

Greenstone-Tech can customize power level, scanning settings, automation logic, and system integration to match your workpiece size, line speed, contamination type, and workshop layout.

ArticolulSpecificații
Numele produsuluiLarge-Area Laser Cleaning Equipment
MarcaGreenstone-Tech
Putere medie laser1000W–6000W
Laser Cleaning Efficiency10–100 m²/h
Laser Center Wavelength1064 nm
Lățime de scanareAdjustable 5 mm – 150 mm
Max Workpiece SizeWidth 6 m, Length 50 m
Sursă de alimentareAC 380V ±10%
Frecvența50/60 Hz
Consumul de energie (@25°C)25 kVA
Necesarul de aer comprimat0,6 MPa, aer comprimat curat fără ulei și fără apă
Temperatura de funcționare0°C - 40°C
Umiditate de funcționare30% – 80%
