GST-Y150 Selective Electron Beam Melting(EBM/SEBM) Equipment (R&D and small batch manufacturing version)
Presentation of the equipment's characteristics
The forming process is open source, and the development of new material systems is convenient and fast.
Applicable to the research and development of new materials and small-batch production in universities and research institutes.
Maximum forming size: 170×170×180 mm; Applicable materials: titanium and titanium alloys, refractory metals (tungsten, molybdenum, tantalum, niobium), titanium aluminum and other brittle and difficult-to-process materials, copper and copper alloys, zirconium alloys, nickel-based high-temperature alloys, ceramic/metal composite materials, etc.
- Open-source forming process, enabling fast and convenient development of new material systems.
- Low powder loading per batch, reducing equipment usage and maintenance costs.
- Optional smaller build chamber (100×100×140 mm) for greater material flexibility.
- Powder bed preheating temperature up to 1300℃, reducing forming stress and allowing the production of brittle, crack-prone materials.
- Utilizes downward powder feeding technology with real-time monitoring of powder flow, improving powder spreading accuracy and stability while reducing powder flowability requirements during printing.
- High electron beam penetration, deeper molten pool, high energy absorption efficiency, faster forming speed, and denser formed parts.
- Vacuum environment printing results in minimal oxygen increment, purer parts, greater design freedom, less support, and no need for post-heat treatment.
- Equipped with multiple safety protection systems and automatic fault handling.
Supporting materials: Titanium and titanium alloys, refractory metals (tungsten, molybdenum, tantalum, niobium), brittle and difficult-to-process materials such as titanium aluminum, copper and copper alloys, zirconium alloys, nickel-based high-temperature alloys, ceramic/metal composite materials, etc.
Max. build size | 170×170×180 mm |
Beam power | 3 kW |
Electron accelerating voltage | 60 kV |
Beam current | 0~50 mA |
Filament life | >60 h |
Cathode type | Directly heated tungsten cathode |
Min. beam diameter | ≤300 μm |
Max. powder bed preheat temperature | 1300 ℃ |
Ultimate vacuum | 5×10-3 Pa |
Build accuracy of components | ±0.2 mm |
External dimension | 2000×1200×2150 mm3 |
Machine weight | 1.5 t |
CAD (interface) | STL |
Control software | SEBM-ICS |
